Wholesale Urban Mini 20-Inch E-Bike – 36V 300W Lightweight Commuter

The HAIDONG 20-inch compact urban electric bike combines a sleek, minimalist frame with a responsive 300W geared rear hub motor and premium 36V LG battery cells (5Ah/10Ah options). Lightweight (33–35 lbs) and engineered for versatile urban mobility, it offers up to 16 mph top speed and a range of up to 20 miles. Ideal for global B2B distributors seeking high-demand, small-footprint city commuters.

Key Features & Selling Points

  • Lightweight & Ultra-Compact Frame: Weighing just 33–35 lbs with a length under 50 inches, this model provides agile handling and effortless storage for urban riders.

  • Reliable Powerhouse: Equipped with a 300W geared rear hub motor delivering smooth acceleration and a top speed of ~16 mph via throttle control.

  • Premium LG Battery Configuration: Options for 36V 5Ah (180Wh) or 10Ah (360Wh) LG lithium-ion battery packs, providing up to 20 miles of range per charge.

  • Enhanced Safety & Control: Features a 160mm rear mechanical disc brake integrated with a motor power cut-off system for immediate, reliable stopping power.

  • Universal Rider Fit: Accommodates a wide range of rider heights (4’1″ to 6’2″) with a maximum payload capacity of 240 lbs and a low standover height of 23.6 inches.

  • Overview
  • OEM/ODM Options
  • Certifications
  • Support & Warranty
  • 5A/10A
    Samsung/LG battery
  • 300w
    Rear brushless motor
  • 16Mph
    Max Speed
  • 10/20 miles
    Range
  • 20" x 2.4" Kenda
    Tires
  • 33–35 lb (varies by battery)
    Weight

Specifications

  • Motor 36V 300W uitra rear brushless
  • Battery 36V LG pack, 5Ah or 10Ah (180–360 Wh)
  • Mode Throttle twist grip
  • Display LCD battery level display
  • Max Speed 16Mph
  • Tire 20" x 2.4" Kenda
  • Brake rear mechanical disc, 160 mm, with motor cutoff
  • Weight 33–35 lb (varies by battery)
  • Load capacity 240 lb
  • Carton Size length < 50", handlebar height < 42", standover 23.6"
